The Cruciform mounting plate for Tiomos - 348.38.555 by Hafele represents a refined fusion of quality and functionality. This mounting plate is specifically designed for Grass Tiomos Mirro concealed hinges, facilitating seamless assembly processes. Crafted from durable steel and finished with nickel plating, it promises longevity and resilience.
With a drill hole diameter of 5 mm and a drilling depth of 12 mm, it accommodates screws of 13.50 mm in length. The screw distance of 32 mm and edge distance of 37 mm provide flexibility during installation. Additionally, the height adjustment feature allows for a ±2.5 mm range, enabling precise adjustments during assembly.
The cruciform mounting plate stands out for its practicality and reliability, making it an essential component for hinge installations.
