Passage width = 540 mm
Housing made of stainless steel satin finish AISI 304.
Base columns prepared for installation of a barrier tape, slot existing.
Two door leaves made of colourless PETG, lightgrey rectangles, upper edge 1.000 mm.
Total width = 990 mm
Interlock height = 1520 mm
Interlock length = 1700 mm
Security and safety sensor system including luggage detection.
10 mm tempered safety glazing in the guide elements. Cut out in the bottom area of the lateral privacy glass, ESG 10 mm frosted for A4 paper.
Without cut out for Printer.
LVDS 7" display
Stainless steel satin finish. Traveler interface stainless steel satin finish
Entrance free after authorisation
Exit always closed
Type 2 power assisted motion; 2 servo positioning drives / 2 directions electrically controlled, drives integrated in the rotating tube.
Signal device (arrow/cross pictogram) on entry side.
Acoustic signal to announce unauthorised entry.
Lockable components with Kaba lock cylinders for maintenance cover and square for printer doors.
Incorrent behaviour during Boarding (block lock for 5 seconds) standard tailgating IPC CV05 4GB RAM
In the case of a power failure: door leaves can be moved freely!
Control units and power supply unit are integrated in the unit.
Power supply 100–240 VAC 50/60 Hz
Dowelled on finished floor level FFL.
Not suitable for outdoor installation!
Prot. class Housing IP32 Components conducting supply voltage IP42
