Specification:
• 1 function and 1 additional outlet
• Select push-button on/off control for 1 outlet
• precise temperature control thanks to vertical handle structure and haptic feedback from the thermostat handle
• water flow control with stop function
• thermostat cartridge, Start/stop valve to operate the functions
• maximum flow rate at 3 bar: 32,8 l/min
• flow rate upper outlet: 23 l/min
• flow rate lower outlet: 23 l/min
• min. operating pressure: 1 bar
• max. operating pressure: 10 bar
• flat escutcheon for more space in the shower
• escutcheon can be aligned by +/- 3°
• easy installation due to pre-assembled function block
• handles always at the same height regardless of the installation depth of the basic set
• Safety stop at 40 °C
• temperature limitation adjustable
• the thermostat offers the possibility for thermal disinfection
• material button: metal
• material handles: metal
• connection type: basic set iBox universal 2 (# 01400180)
• thermostat is delivered with buttons hand shower, bath tub, whirl, body shower and On/Off
